PD GaN Adapter 65W S3D0

Download instructions in PDF

Cubenest S3D0 is a powerful and compact USB adapter with GaN technology for fast and safe charging up to 65 W. It offers three outputs - 2× USB-C and 1× USB-A - for simultaneous charging of multiple devices. Ideal for laptops, tablets, phones and accessories at home, in the office and on the go.

Package includes

• 1x 65W PD adapter
• 1x USB-C to USB-C cable (1m)
• User manual

Product Specifications

• Model: S3D0
• Safety protection: over-voltage and over-temperature protection, short-circuit protection
• Total power: 65 W
• Supports technologies: PD 3.0, PD2.0, PPS, QC4.0+, QC 3.0, QC2.0, DCP, FCP, SCP, AFC, Apple 2.4, Samsung 2.0, BC1.2, PE2.0, PE1.1
• Ports: 2× USB-C, 1× USB-A
• Fast Charging Parameters:
• Input: AC 100-240V~50/60Hz 1.5A
• USB-C1 output power: 5V/3A, 9V/3A, 12V/3A, 15V/3A, 20V/3.25A
• USB-C2 Output Power: 5V/3A, 9V/3A, 12V/3A, 15V/3A, 20V/3.25A
• USB-A output power: 3.4-5.5V/5A, 5/3A, 9V/3A, 12V/3A, 20V/3A
• Charging multiple devices simultaneously: The adapter allows you to charge three devices simultaneously. When multiple devices are connected, the power is split between each port. To achieve maximum power on a particular port, we recommend connecting fewer devices.

Port wiring diagram

.

Safety instructions

⚠️ USE only high quality, certified and undamaged cables.
⚠️ ENSURE adequate ventilation of the adapter during operation.
⚠️ DO NOT expose the adapter to extreme temperatures, humidity, or direct sunlight.
⚠️ PROTECT the adapter from water and other liquids.
